Visualizing React re-renders for educational purposes

For my workshops (and for this blog), I like to show the renders of the components as they happen. This is a great way to understand how React works and how developers can optimize their applications. This has also helped me a lot in my preliminary work for my workshops to get a deeper understanding of how React does its magic.

In this article, I’ll show you how I build a custom debug component that visually highlights re-renders.

The Box component: how it works
- Tracking Render Count
- Visual Highlight Effect
Using Box in a component

The Box component: how it works

Now, let’s look at how to build this debug component. I call it Box because it wraps around your components, creating a visual “box” that highlights when re-renders occur.

Here’s the implementation:

import { useRef, useEffect } from "react";

/**
 * The Box Component displays a blinking outline when it re-renders
 */
export function Box({
  children,
  wrapperClassName,
  className,
  name = "Component",
  ...props
}: React.HTMLProps<HTMLDivElement> & {
  name?: string;
  wrapperClassName?: string;
}) {
  const ref = useRef<HTMLDivElement | null>(null);
  const renderCount = useRef(0);

  renderCount.current += 1;

  useEffect(() => {
    if (!ref.current) return;
    const originalBorder = ref.current.style.border;
    const originalBoxShadow = ref.current.style.boxShadow;

    ref.current.style.border = "2px solid #8b5cf6";
    ref.current.style.boxShadow = "0 0 12px 4px rgba(139, 92, 246, 0.5)";

    const revert = () => {
      if (!ref.current) return;
      ref.current.style.border = originalBorder;
      ref.current.style.boxShadow = originalBoxShadow;
    };

    const timer = setTimeout(revert, 200);

    return () => {
      clearTimeout(timer);
      revert();
    };
  });

  return (
    <div
      ref={ref}
      {...props}
      className={`border-2 border-purple-500/30 bg-indigo-950/20 backdrop-blur-sm p-6 rounded-lg relative
      transition-all duration-200 shadow-md hover:shadow-lg ${wrapperClassName || ""}`}
    >
      <div
        className="absolute top-2 right-2 bg-gradient-to-r from-purple-700 to-indigo-700
      text-white text-xs font-medium px-3 py-1 rounded-full shadow-sm"
      >
        {name} rendered: {renderCount.current}
      </div>

      <div className={`pt-2 pb-2 ${className}`}>{children}</div>
    </div>
  );
}

Let’s analyze the key parts of this component:

Tracking Render Count

I use a useRef to persist the render count between renders. Each time the component renders, we increment this counter and display it in the UI. This gives us a visual indication of how many times a component has re-rendered.

const renderCount = useRef(0);
renderCount.current += 1;

This is often quite useful, for instance, with React strict mode when a component renders twice in development mode.

Visual Highlight Effect

Then for the visual effect, I simply add a useEffect to add and remove a border and a box shadow. It’s one of the rare cases where I use a useEffect without a dependency array as I want it to run on every render.

useEffect(() => {
  if (!ref.current) return;

  const originalBorder = ref.current.style.border;
  const originalBoxShadow = ref.current.style.boxShadow;

  ref.current.style.border = "2px solid #8b5cf6";
  ref.current.style.boxShadow = "0 0 12px 4px rgba(139, 92, 246, 0.5)";

  const revert = () => {
    if (!ref.current) return;
    ref.current.style.border = originalBorder;
    ref.current.style.boxShadow = originalBoxShadow;
  };

  const timer = window.setTimeout(revert, 200);

  return () => {
    revert();
    window.clearTimeout(timer);
  };
});

Using Box in a component

The usage is then quite simple. You just need to wrap your component with the Box and add a name prop to identify the component. Here’s an example:

import { Box } from "./Box";

function Counter() {
  const [count, setCount] = useState(0);

  return (
    <Box name="Counter">
      <div>
        <p>Count: {count}</p>
        <button onClick={() => setCount(count + 1)}>Increment</button>
      </div>
    </Box>
  );
}

Et voilà!

We have a quite useful component for educational purposes. As a sidenote, I used it a lot in this good old repository react-sandboxes for my workshops.

Feel free to use it in your own projects or adapt it to your needs.
